In terms of the formal design language, the objective was to create a sophisticated interaction between the sculptural surfaces of the F12berlinetta and a more graphic treatment of the various new aerodynamic features. The best testament to this intent is the evolution of the Aerobridge, the design of which is further enhanced by the use of bare carbon-fibre. Developed in such a technical manner, this component combines with the other details in creating a coherent aesthetic approach to the whole car.
SPORTY AND SPARTAN
The car’s uncompromising sportiness is expressed with the same degree of purity in the deliberately Spartan cockpit. The wrap-around effect that embraces the driving position is intensified by the use of carbon-fibre housings for the instruments and satellite pods. The door panels have been pared back to a single carbon-fibre shell, while the glove compartment has disappeared to be replaced by simple knee padding.
Alcantara rather the traditional leather was chosen for the cabin trim, technical fabric for the seats and patterned aluminium instead of mats for the floor, once again with the aim of saving every last ounce of weight.
THE ENGINE IS THE F12BERLINETTA’S 6262CC 65° V12 ON WHICH FERRARI ENGINEERS WORKED TO BOOST MAXIMUM POWER OUTPUT FROM 730 HP TO 769 HP AT 8,500 RPM, YIELDING A SPECIFIC POWER OUTPUT OF 3.9 LBS PER HP.
The engine’s sporty response is assured by a maximum torque figure of 520 lb-ft (up from 509 lb-ft) at 6,750 rpm with 80% already available at 2,500 rpm, resulting in unparalleled, progressive pick-up all the way to the red-line at 8,900 rpm.Numerous modifications have been developed for this engine, starting with the use of race-inspired mechanical tappets and variable-geometry intake trumpets used on Formula 1 cars which help boost volumetric efficiency at high revs.
The F12tdf is equipped with a specific version of the F1 DCT with 6% shorter gear ratios that delivers 30% faster upshifts and 40% faster downshifts.
Take advantage of the advanced technology on our website to make your shopping experience faster and easier. For example, you can save cars of interest and receive alerts when new offers become available, the price changes or the vehicle sells — simply by providing an email address! Better yet, you can pick up where you left off at home, at work or on your mobile phone by creating your account.
The rear spoiler is now 60mm longer and 30mm higher, while the rake of the rear screen has been made more vertical to extend the surface area over which the spoiler can generate downforce and to capitalise on its advantages more effectively. The concave curvature of the rear luggage hatch either side of the rear screen further enhances the solution. Three pairs of GT-racing-derived strakes have been adopted on the aerodynamic underbody and are responsible for 30% of the increase in downforce compared to the F12berlinetta. The rear diffuser has been completely redesigned and now sports a system of three active flaps. It has been split into three channels and features curved fences and vertical splitters to boost the power of the vortexes and enhance the expansion of the flow in the horizontal plane. This radical aerodynamic design work essentially created a whole new car that also marks a major stylistic departure from the F12berlinetta.
Development affected every area of the car’s surface, producing striking elements that lend its forms a unique sleek power. At the front, a highly complex bumper contributes to downforce generation. It features a radically scooped lower section and incorporates a competition car-inspired splitter, dive planes, floor wings and louvres to boost the efficiency of both the sides and the underbody. The Aerobridge on the car’s front flank has been redesigned to increase the energising effect of the air flow along the top of the sides, while at the rear, louvres on the wheelarch create a depression that extracts air from the inner wheelarch, thereby increasing the efficiency of a section of the underbody that is usually little used in generating downforce.Create an Account
To enable even gentlemen drivers to make full use of the performance, Ferrari developed its new Virtual Short Wheelbase system. Debuting on the F12tdf, the rear axle is active, allowing the rear wheels to pivot around a vertical axis. Using model-based control logic developed entirely in-house by Ferrari, the rear axle steering automatically adjusts the rear wheels, working out the optimal steering angle as a function of the steering wheel angle, speed of steering inputs and vehicle speed. The Virtual Short Wheelbase improves the car’s responsiveness to make it feel more agile, with instantaneous turn-in that can be best appreciated on twisty roads and on more technically challenging tracks while, at the same time, improving stability at high speeds.
They drew on the wealth of experience built up in the XX programmes which are dedicated to developing extremely high performance cars driven by non-professional drivers. Extraordinary chassis dynamics, in terms of maximum lateral acceleration and responsiveness, are in part achieved by the increase in the front tire dimensions, which jump from 255 to 275, along with the front channel size - up from 9.5” to 10”. This modification guarantees higher lateral acceleration generated by the front axle but, alone, this would have caused oversteer on the limit, making the car more challenging for less expert drivers.
|Overall lenght||183.3 in|
|Overall width||77.2 in|
|Front track||65.9 in|
|Rear track||63.7 in|
|Dry weight*||3119.5 lb|
|Kerb weight*||3351.0 lb|
|Weight distribution||46% Front - 54% Rear|
|Fuel tank capacity||24.3 US gal|
|Bore and stroke||3.7 x 2.96 in|
|Total displacement||382.13 cu in|
|Maximum power **||769 hp at 8500 rpm|
|Specific Output||125 bhp/l|
|Maximum torque||519 lb-ft at 6250 rpm|
|Maximum revs per minute (limiter)||8900 rpm|
|Front (winter)||255/35 ZR|
|Rear (winter, can be used with chain)||305/35 ZR|
|Type||7-speed F1 Dual-Clutch gearbox|
|Maximum speed||over 211 mph|
|0-62 mph||2.9 sec|
|0-124 mph||7.9 sec|
|62-0 mph||100 ft|
|124-0 mph||396 ft|
|Front||15.7 x 8.8 x 1.5 inch|
|Rear||14.2 x 9.12 x 1.3 inch|
|ESC||Electronic Stability Control|
|High Performance ABS/EBD||High performance Antilock Braking System/Electronic Brakeforce Distribution|
|F1 Trac||F1 Traction Control|
|E-diff 3||Third Generation of Electronic differential|
|SCM-E with dual coil||Magnetorheological suspension control with dual coil system|
|Combined||4.0 G/0.6 Mi|
|* With optional weight-saving content|
|** Engine power is expressed in kW, in accordance with the International System of Units (SI) and in CV (1KW= 1.3596216 CV). With dynamic overboost|
|*** With HELE system|
